| Military/High-Rel: | N |
| Tech.: | CMOS |
| Gate Capacity: | 4200 |
| Configurable Logic Blocks: | 144 |
| Number of User I/Os: | 74 |
| Program Data (Bits): | 30784 |
| Logic Level Family: | CMOS and T |
| Maximum Toggle Rate: | 100M |
| VOL Max.: | 0.4 |
| @Iol (A): | 4.0m |
| VOH Min.: | 3.86 |
| @IOH (test): | 4.0m |
| VIH Min. (TTL) (V): | 2.0 |
| VIL Max. (TTL) (V): | 0.8 |
| VIH Min. (CMOS) (V): | 3.5 |
| VIL Max. (CMOS) (V): | 1.0 |
| Vsup (+) Maximum (V): | 7.0 |
| Digital Input V Max (V): | 7.5 |
| Nom. Pos. Supp: | 5 |
| Quiescent Current Max (CMOS): | 500u |
| Quiescent Current Max (TTL): | 10m |
| Maximum Operating Temp (øC): | 70 |
| JEDEC Std 30 Outline Code: | S-PQCC-J |
| Package Body Material: | Plastic |
| Package Style: | QCC-J |
| Mounting Style: | S |
| # Pins: | 84 |
| |
