| Minimum Operating Temp (øC): | -40 |
| V(GT) Max.(V): | 3.0 |
| I(T(RMS)) Max. (A): | 25 |
| I(TSM) Max. (A): | 250 |
| # & Name of Quick-Connects: | G-MT1-MT2 |
| @Temp. (øC) (Test Condition): | 125õ |
| V(DRM) Max. (V): | 400 |
| V(DRM) Max. (V): | ‘ |
| Mounting Style: | T |
| @I(T) (A) (Test Condition): | 25 |
| Package Style: | MODULE-var |
| V(T) Max. (V): | 1.4 |
| I(GT) Max. (A): | 50m |
| Mounting Profile Code: | M:HL030HD4.2 |
| I(H) Max. (A) Holding Current: | 30m |
| t(gt) Typ. (s): | 10u |
| dv/dt(c) Min. (V/us): | 6 |
| @Temp. (øC) (Test Condition): | 74# |
| @ t(w) (s) (Test Condition): | 8.3m |
| Thermal Resistance Junc-Case: | 1.6 |
| Maximum Operating Temp (øC): | 125õ |
| I(D) Max. (A) Leakage Current: | 5.0m |
| dv/dt Min. (V/us): | 50 |
| @I(T) (A) (Test Condition): | 35 |
