Minimum Operating Temp (øC): | -40 |
V(GT) Max.(V): | 3.0 |
I(TSM) Max. (A): | 1.5k |
# & Name of Quick-Connects: | 2G |
@Temp. (øC) (Test Condition): | 125õ |
V(DRM) Max. (V): | 1.2k |
@Temp. (øC) (Test Condition): | 80# |
@Temp. (øC) (Test Condition): | |
Mounting Style: | T |
Package Style: | MODULE-var |
V(T) Max. (V): | 1.7 |
I(GT) Max. (A): | 150m |
Mounting Profile Code: | M:HL080HD6.4 |
I(H) Max. (A) Holding Current: | 250m |
V(RRM) Max. (V): | 1.2k |
# & Name of Screw Terminals: | A-K-AK |
t(gt) Typ. (s): | 1uý |
I(T) Rated Maximum (A): | 55± |
Thermal Resistance Junc-Case: | 0.29 |
Maximum Operating Temp (øC): | 125õ |
t(q) Typ. (s): | 80u |
I(D) Max. (A) Leakage Current: | 15m |
dv/dt Min. (V/us): | 500 |
@I(T) (A) (Test Condition): | 200 |
