| Minimum Operating Temp (øC): | -55 |
| Maximum Isolation Voltage (V): | 7.5k |
| @I(F) (test) (A): | 10m |
| @If (A): | 500u |
| V(CE)sat Max. (V): | 500m |
| P(D) Max. (W): | 250m |
| V(FM) Max.(V) Forward Voltage: | 1.5 |
| Mounting Style: | T |
| Minimum Current Xfer Ratio (%): | 250 |
| Vbr CEO: | 30 |
| Package Style: | DIP |
| Military/High-Rel: | N |
| I(F) Max. (A) Forward Current: | 80m |
| @If (A): | 50m |
| @I(C) (A) (Test Condition): | 2.0m |
| I(C) Max. (A): | 100m |
| Number of Channels: | 1 |
| @VCE (test): | 5.0 |
| Maximum Operating Temp (øC): | 100 |
| t(resp) Max.(s) Response Time: | 1.3uª |
