| @I(T) (A) (Test Condition): | 424 |
| @Temp. (øC) (Test Condition): | 85# |
| Maximum Operating Temp (øC): | 130õ |
| Minimum Operating Temp (øC): | -40 |
| I(T) Rated Maximum (A): | 135± |
| Thermal Resistance Junc-Case: | .2 |
| Mounting Profile Code: | M:HL080HD6.5 |
| dv/dt Min. (V/us): | 500 |
| Package Style: | MODULE-var |
| # & Name of Screw Terminals: | A-K-AK |
| I(GT) Max. (A): | 200m |
| # & Name of Quick-Connects: | 2G-2GR |
| V(GT) Max.(V): | 3 |
| # & Name of Turret Terminals: | ä |
| Mounting Style: | T |
| I(D) Max. (A) Leakage Current: | 50m |
| I(H) Max. (A) Holding Current: | 500m |
| V(DRM) Max. (V): | 1.2k |
| I(TSM) Max. (A): | 2.8k |
| V(RRM) Max. (V): | 1.2k |
| @ t(w) (s) (Test Condition): | 8.3m |
| V(T) Max. (V): | 1.7 |
| @Temp. (øC) (Test Condition): | 130õ |
| t(q) Typ. (s): | 50u |
