Price Per Quantity
| Military/High-Rel: | N |
| Package Style: | R-Angle PC |
| Color: | Red |
| Lens Diam. (mm): | 2.0 |
| Overall Height (mm): | 6.4 |
| Lens Type: | Diffused |
| Luminous Intensity Min. (Cd): | 600u |
| Wvlngth (Peak): | 650n |
| V(FM) Max.(V) Forward Voltage: | 2.4 |
| @I(F) (test) (A): | 20m |
| If Max (A): | 4.0m |
| Minimum Operating Temp (øC): | -55 |
| Maximum Operating Temp (øC): | 100 |
| Package Style: | Lmp-5 |
| P(out); in Watts | † |
| Description: | Logic Indicator |
