| Maximum Isolation Voltage (V): | 2.5k |
| Number of Channels: | 1 |
| Vbr CEO: | 30 |
| Minimum Current Xfer Ratio (%): | 500 |
| @If (A): | 10m |
| @VCE (test): | 10 |
| t(resp) Max.(s) Response Time: | 5.0u |
| I(C) Max. (A): | 100m |
| V(FM) Max.(V) Forward Voltage: | 1.5 |
| @I(F) (test) (A): | 10m |
| I(F) Max. (A) Forward Current: | 100m |
| I(CEO) Max. (A): | 100n |
| @VCE (test): | 10 |
| P(D) Max. (W): | 200m |
| Minimum Operating Temp (øC): | -55 |
| Maximum Operating Temp (øC): | 100 |
| Package Style: | DIP |
| Mounting Style: | T |
| Junction Temperature | ò |
